Autel MaxiIM KM100 Key Fob Programmer Universal Key Generator Kit Key Programming Tools Free Update

Why choose Autel MaxiIM KM100?

1. Free Update Online Lifetime

2. Global Version No IP Blocking Problem

3. Supporting 8 Key Series And 37 Models

4. Simple Operation, Guided User Instructions, Easy To Use

5. Industry-Leading Coverage Of IMMO Learning Via OBD For More Than 90% Of Models

6. Multi-Language Supported: English, German, Spanish, French, Polish, Portuguese, Italian, Dutch, Swedish, Russian, Korean, Japanese, Chinese

7. KM100 Adopts a High-Resolution Display Screen of 1280*720, and Supports Touch-Screen Operation, which is sensitive, convenient, and fast to use.

8. Support Chip Simulation for Emergency Use (for ID46 47 48 49 4A 8A), which can be used in an emergency when there is no chip around.

10+ Hot & Special Functions, All- in-one Tool Solutions for Auto Keys!

Apart from professional features such as Universal Ke-y Generation, Complete IMMO Key Learning, 2023 Autel MaxiIM KM100 also supports 10+ hot and special functions:

1. IMMO Data Processing: load the IMMO related ECU information of a vehicle to calculate a password and other IMMO information, which will be written into the transponder of the vehicle, the processed transponder can be used to start the vehicle, in other words, you now have an extra ke-y

available.

2. Ke-y Unlocking (Ke-y Renewal): enables you to renew a used smart key to unlock a new car, which is achieved by renewing the firmware of the used smart key via cable connection, working on 36 vehicle makes.

3. Toyota Smart Un-locking: With this function, you can unlock other Toyota models with your Toyota smart ke-y. Unlocking of the 4D 40/80 bit and 8A 128 bit original Toyota smart chips is supported.

4. Button Adjustment: assign the button functions of the Autel universal ke-y.

5. Universal Ke-y Information Detection: especially designed to read the Autel universal key information, including the serial number, key ID, and IMMO version, etc.

6. Ignition Coil Detection: enables the key tool to gather the data of the IMMO protocol and transponder type of the vehicle, while Autel old models IM508/ IM608 cannot support this special functions.

Professional & Complete IMMO Ke~y Learning Via OBD on 99% Vehicles, Meet All Your Needs!

The IMMO application requires a data link to the IMMO electronic control system of the test vehicle for diagnosis via OBDII connection. The application retrieves vehicle IMMO information and performs IMMO related functions. For example:

1. Read PIN;

2. Key Learning;

3. Remote Control Learning;

4. Remote Control Add;

5. All-Key-Lost;

6. IMMO data backup/restore;

7. IMMO ECU Reset/ Adaptation/ Refresh/ Coding;

8.And More...

Extensive Transponder Functions, Solve Almost Ch~ip Related Issues!

1. Transponder Reading: access to some basic information of the key, including chip type, IMMO type, transponder ID, locking status, and code mode.

2. Transponder Cloning: detect the transponder and vehicle informationin order to decrypt a code which shall be used to directly clone and generate a functional transponder for your vehicle. The whole process saves the trouble of using the old OBD approach.

3. Transponder Editing:read and edit transponder information such as its configurations and EEPROM data. Choose an IMMO type (which can be accessed by the transponder reading function) and start editing according to your needs.

4. Transponder Generation: generate a transponder accommodating different protocols or models using a blank transponder.

5. Transponder Simulation: used to simulate the KM100 as a transponder using a variety of IMMO protocols. This function is particularly useful when your vehicle needs emergency start or such.

6. Conversion between Ford ID63 & ID83: especially designed for the conversion between two types of Ford transponder — ID63 and ID83.

Specification:

Dimensions (WxHxD): 200mm(7.9") x 89 mm (3.5") x 22 mm (0.87")

Weight: 352.7g (0.8 lb)

Screen: 5.5-inch screen with 1280 x 720 resolution

Processor: Rockchip PX30 (4x ARM Cortex-A35 1.5GHz)

Operating System: Android TM9.0

Memory: 2GB RAM/64GB on-board memory

Camera: 8 megapixels

Connection: Wi-Fi, Bluetooth 5.0, USB 2.0 type C

Battery: 4950mAh lithium-polymer battery

VCI: V200

Input: 5V/2A

Sensor: Ambient light sensor

Audio Input/OutputMIC: supported

Speaker: supported

Operating Temp: -10 to 45°C (14 to 113°F)

Storage Temp: -20 to 60°C (-4 to 140°F)
