5Pcs/lot Truck OBD2 Adblue Emulator for Benz/DAF/Iveco/MAN/Scania/Volvo Euro6 Truck Diesel Emulator Adblue OBD2 Diagnostic Scanner AdblueOBD2 Emulator

OBD2 Emulator for MAN Euro6 is specially for Man Truck Euro6

After installing Euro6 Emulator, you can re move:

D sensors – YES

N sensor – YES (only in D don’t remove first N sensor !!!)

temp. sensor (s) – YES

pump – YES

level sensor – YES

ECU – YES

Kindly note:

It is possible to disable system by installing an emulator (programmable device) into the vehicle. You can switch it on/off anytime.

EURO6 Emulators using guide:

Emulator FOR Man Euro 6 does not need to be learned. You install emulator under the metal cover of ump on the right side behind the cab, and disconnect plug from Pump and connect emulator.

Next, you need to remove the fuses:

F894(Multisensor In tank)

F738 (+30 Signal of pump)

F1084 ( sensor Upstream)

Fuse F737 is now fuse of emulator.

Fuse F1109 is the fuse of sensor Downstream and A1191 mufler temperature sensor. This sensor needs to work correctly for DPF regeneration.

Finally, you need to remove Power from downstream sensor. There are two ways options, one is to cut pin 1 in sensor plug, the other way (better) is to remove pin 10 in X3212 plug. This plug is visible on rear of engine on the right side. This is TE plug (16 pin) with yellow key.

Adblue Emulator For Mercedes Benz Euro6 Truck Diagnostic Scanner

For Mercedes Euro 6 AdBLue Remove Emulator Installation

Behind fuses in the middle is a plug- as in the price (not right like in m-anual-correct is middle)

Connnection colors-White(Emulator side) with Blue (Truck side) with White (Truck side)

Red wire from emulator connection with any(+)after ignition

Black i GND

Next step is remove Fuse

F23 Thats all

For Mercedes Atego Euro 6 AdBlue Remove Emulator Installation

You must locate the ACm Module and remove the socket.

The cable should be installed as shown in the picture below.

Emulator White cable(CAN H) ----->Atego vehicle socket 10 pin(CAN H)

Emulator Brown cable (CAN L) -----> Atego vehicle socket 20 pin (CAN L)

Emulator Red (+) ----->Atego vehicle Positive(+)Cable

Emulator Black(-) ----->Atego vehicle GND (-)

After installation, you must remove errors with fault detecting device.

The Mercedes DTC fault code eraser can also be used to erase the fault in your Atego vehicle

You will not mount the socket back into the ACM module Isolate the Atego ACh nodule without damage.

Adblue Emulator For Scania Euro6 Truck Diagnostic Scanner

Not need to be leaming, you have to mount emulator in the plug of the EEC(AdBlue)ECU(in the pink one),Yon can find EEC ecu ta the center of the vehicle frame.Two big plugs(one is pink) in this m-anual you will find pin mumber of the EEC plug,also colours cables of EEC and Emulator.

You have to mount emulator in the plug of the EEC(AdBlue)ECU(in the pink one),Yon can find EEC ecu ta the center of the vehicle frame.Two big plugs(one is pink)

in this m-anual you will find pin mumber of the EEC plug,also colours cables of EEC and Emulator.

Connect wires of the emulator with this table as reference:

Red(Vcc)-PIN 12 (green) Cut the cable after connect emulator to truck side

Black (GND)-PIN 4 (fat black)

Yellow (CAN H)-PIN 22 (orange)

Green (CAN l)-PIN 19 (fat black)

Adblue Emulator For VOLVO Euro6 Truck Diagnostic Scanner

Top 4 Reasons To Get V-olvo Euro6 Adblue Emulator:
Avoid all of adblue system errors
Do not need adblue fuel
Do not get and adblue or NOx fault
Prevent torque loss

Importance of Volvo Euro6 Adblue Emulator:
Trucks generally give adblue or nox system errors so work hard. Your truck can cause loss so some adblue errors or fault lights.
These problems cause you money and time. After installing adblue remove emulator, you dont get other adblue errors and you do not need to add adblue fuel. After the installation, your adblue fuel level will be up automatically.

Adblue Remove emulator disable these systems:
AdxBlue system (All)
AdxBlue NOX sensor
DPF system
DPF temperature sensors

DPF regeneration Supported Models:
Euro 6 for the Volvo FMX Series
Euro 6 for the Volvo FH Series
Euro 6 for the Volvo FM Series

Newest Emulator for DAF Euro6 Emulator Truck Diagnostic Tool

DPF regeneration Supported Models:

Euro 6 for the for FMX Series

Euro 6 for the for FH Series

Euro 6 for the for FM Series

NOTE:

You can see some DTC code about system after the connection. And you may need erase with diagnostic device.
